Ozone Water Treatment
Ozone is a powerful oxidant that is 1.5 times stronger than chlorine and has a reaction time 3000 times faster than chlorine. It is an extremely effective disinfectant and oxidant for water treatment applications.
Ozone is effective against bacteria, viruses, protozoa, and algae. It also effectively removes color, odor, and taste problems, and oxidizes iron, manganese, and sulfides.
Our ozone and oxygen systems are used in various applications including drinking water treatment, wastewater treatment, and industrial processes. Ozone treatment provides multiple benefits including disinfection, oxidation of iron and manganese, color removal, and ozone destruction of organic contaminants.
We provide complete system solutions including ozone generators, oxygen concentrators, contact chambers, and destruct units. Our team offers professional installation, maintenance, and technical support to ensure optimal system performance.
Experienced in Ozone & Oxygen Systems
Artha Inti offers ozone and oxygen solutions for various industries requiring advanced oxidation and disinfection. Our team has extensive experience in designing, installing, and maintaining ozone generation systems for diverse applications.
We understand the unique requirements of each application and provide customized solutions that ensure optimal ozone delivery and contact time. Our expertise spans from small-scale residential applications to large municipal and industrial installations.
Our team has successfully installed and maintained ozone and oxygen systems across multiple sectors. We offer comprehensive support including system sizing, installation, operator training, and preventive maintenance programs.
All our ozone systems are designed with safety in mind, featuring proper containment, ventilation, and ozone destruct capabilities to meet occupational safety standards.
Our Ozone Products
HY-GOX Series - Integrated 2 Tower Oxygen Concentrator
Download CatalogIntegrated 2 tower oxygen molecular sieve concentrator. Produces high-purity oxygen (≥90%±3%) for various industrial applications including water treatment, fish farming, and medical use.
Key Components
- • Air intake filter
- • Air compressor
- • 4 Fans
- • A molecular sieve
- • B molecular sieve
- • Dry molecular sieve
- • Power Board
- • Oxygen tank
- • Regulating valve
- • Oxygen flow meter
- • Gas water separator
- • Condenser
Specifications - HY-GOX Series (Desktop)
| Parameter | HY-GOX3L | HY-GOX5L | HY-GOX8L | HY-GOX10L |
|---|---|---|---|---|
| Oxygen Output | 3 L/min | 5 L/min | 8 L/min | 10 L/min |
| Oxygen Concentration | ≥90%±3% | |||
| Input Voltage | AC220V/50Hz | |||
| Power | <380W | <520W | <780W | <800W |
| Oxygen Output Pressure | >40KPa | |||
| Working Noise | <48dB(A) | |||
| Ambient Temperature | 5-45°C | |||
| Environment Humidity | <80%RH | |||
| Dimension (mm) | 379×240×397 | 430×258×461 | 460×260×510 | 460×260×586 |
| Net Weight | 16.5kg | 22kg | 28kg | 30kg |
Specifications - Overton HY-OXKY Series (Industrial)
Overton oxygen concentrator systems produce high-purity oxygen for various industrial applications. Our oxygen generation systems utilize Pressure Swing Adsorption (PSA) technology to deliver consistent oxygen output with minimal maintenance requirements.
| Parameter | HY-OXKY 20L | HY-OXKY 30L | HY-OXKY 40L |
|---|---|---|---|
| Oxygen Flow Rate | 20 L/min | 30 L/min | 40 L/min |
| Outlet Pressure | 2000KPa | 240KPa | - |
| Power | 2000W | 2900W | 3800W |
| Gas Inlet/Outlet Size | Inlet: G3/4" / Outlet: 10mm | ||
| Voltage | 220V/50Hz | ||
| Dimensions (mm) | 450×450×1310 | 600×450×1350 | 800×450×1350 |
| Key Components | Air Compressor, Gas Tank, Refrigerated Air Dryer, Desiccant Air Dryer | ||
| Working Environment | Humidity: ≤80%RH, Temperature: 5-45°C | ||
Specifications - Overton CH-O Series (Oil-Free Compressor)
products.ozone.oxygen.oilFreeSpecsDesc
| Parameter | CH-0L10C | CH-0L15C | CH-0L20C | CH-0L30C | CH-0L40C |
|---|---|---|---|---|---|
| Oxygen Flow Rate (LPM) | 10 | 15 | 20 | 30 | 40 |
| Oxygen Concentration | 90%±3% | ||||
| Output Pressure | 0.4-0.6 bar(kg) | ||||
| Power (W) | 1060 | 1800 | 2120 | 3180 | 4240 |
| Voltage | 220V 50Hz or 110V 60Hz | ||||
| Dimensions (cm) | 50×84×95 | 67×102×95 | |||
| Configuration | Built-in Oil-Free Air Compressor, Refrigerated Air Dryer, PSA Oxygen Generator | ||||
| Control Features | Door Lock, Amp-meter, Working Indicator, Power Indicator, On/Off, Oxygen Flow Meter, Voltmeter, Oxygen Outlet, Fuse, Power Input | ||||
products.ozone.oxygen.overtonSeriesTitle
products.ozone.oxygen.overtonSeriesDesc
| Parameter | HY-OX50L | HY-OX60L | HY-OX70L | HY-OX80L |
|---|---|---|---|---|
| Oxygen Flow Rate | 50 L/min | 60 L/min | 70 L/min | 80 L/min |
| Outlet Pressure | ≥40KPa | |||
| Power | 800W | |||
| Voltage | 220V/50Hz | |||
| Gas Inlet/Outlet | Inlet: G3/4" / Outlet: 10mm | Inlet: G3/4" / Outlet: 10mm | ||
| Dimensions (mm) | 650×1000×1600 | 800×1000×1600 | 800×1000×1600 | |
| Parameter | HY-OX90L | HY-OX100L | HY-OX110L | HY-OX120L |
|---|---|---|---|---|
| Oxygen Flow Rate | 90 L/min | 100 L/min | 110 L/min | 120 L/min |
| Outlet Pressure | ≥40KPa | |||
| Power | 800W | |||
| Voltage | 220V/50Hz | |||
| Gas Inlet/Outlet | Inlet: G3/4" / Outlet: 12mm | |||
| Dimensions (mm) | 800×1100×1600 | |||
| Key Components | Air Compressor, Air Filter, Refrigerated Air Dryer, Desiccant Air Dryer | |||
| Working Environment | Humidity: ≤80%RH, Temperature: 5-45°C | |||
products.ozone.oxygen.airCompressorSpecsTitle
products.ozone.oxygen.airCompressorSpecsDesc
| Matched O₂ Flow | Compressor Power | Voltage | Dimensions | Gas Storage Tank | Weight |
|---|---|---|---|---|---|
| 50-60 LPM | 7.5 kW | 380V | 750×600×750 | 0.3 m³ | 130+100 |
| 70-80 LPM | 11 kW | 380V | 1000×700×1050 | 0.6 m³ | 226+120 |
| 90-100 LPM | 15 kW | 380V | 1000×700×1050 | 0.6 m³ | 230+120 |
| 100-120 LPM | 22 kW | 380V | 1150×850×1150 | 1 m³ | 310+140 |
Ozonia Membrel MkIV - Electrolytic Ozone Generator
The Ozonia Membrel MkIV is the latest generation of electrolytic ozone generators which uses solid polymer electrolyte and state-of-the-art electronics for ozone production. The Ozonia Membrel MkIV electrolytic process is a unique technology which produces ozone from water instead of gaseous air or oxygen.
The feed water, taken from the main UPW loop, enters the anode chamber of the cell where it is dissociated into its two elements at the contact surface between the anode and the electrochemically stable membrane.
The installation of an Ozonia Membrel MkIV is an effective way of sanitizing a pure water loop. Because the ozone is produced from the water being treated there are no contaminants.
Main Features
- • Electrolytic ozone production
- • Easily upgradeable from 20 to 100 g/h
- • User-friendly with individual cell controls
- • Remote control capabilities
- • No ionic contamination
- • Easily installed, maintaining system integrity
- • Easily upgradeable to 90 g/h
- • Can be integrated with UV ozone destruct unit
Technical Features
- • Power Supply: 1 x 230 VAC +10%/-20%, 50/60 Hz
- • Regulation Range: 8 to 100%
- • Ambient Temperature: +5 to 40°C
- • Design Altitude: <1000 m.a.s.l
- • Humidity: RH <65% (yearly average)
- • Protection Class: IP 54, Nema 12
- • Conformity: EN, IEC, ISO, CE
Materials
- • Enclosure: Stainless Steel ANSI 304
- • Wetted Surfaces: ANSI 316L SS, Titanium, PTFE, PVDF, Viton, Glass
- • Bulkhead Connections: Stainless Steel ANSI 316L SS
- • Mechanical: SERTO bulkhead fitting for 10mm ID / 12mm OD pipelines
Specifications
| Model | Ozone Production (g/h) | Nominal Flow (L/h) | Max Pressure (barg) | Conductivity (µS/cm) | Power Rating (kW) |
|---|---|---|---|---|---|
| Ozonia Membrel MkIV/1 | 3 | 100 | <6 | <20 | 0.46 |
| Ozonia Membrel MkIV/2 | 6 | 200 | <6 | <20 | 0.86 |
| Ozonia Membrel MkIV/3 | 9 | 300 | <6 | <20 | 1.27 |
Dimensions
| Model | Length | Height | Width | Weight |
|---|---|---|---|---|
| Ozonia Membrel MkIV/1 | 30.31 | 28.66 | 15.74 | 56 |
| Ozonia Membrel MkIV/2 | 30.31 | 20.00 | 15.74 | 134.0 |
| Ozonia Membrel MkIV/3 | 30.31 | 28.66 | 15.74 | 145.5 |
Remote Control & Alarms
- • Ozone production ON/OFF
- • Alarm acknowledgement
- • Set-value (4 to 20mA)
- • Collective alarm
Complementary Equipment
- • Ultraviolet ozone destruct unit
- • Residual ozone analyser
- • Vent ozone destructor
- • Tri-clamp inserts for SERTO connections
Applications
- • Drinking water treatment
- • Wastewater treatment
- • Industrial process water
- • Swimming pool disinfection
- • Food and beverage processing
- • Pharmaceutical
Get the Right Ozone Solution
PT. Artha Inti Manunggal specializes in ozone and oxygen systems tailored to meet your specific requirements.
We know you need solutions, not just a filter.
Once we understand your situation we'll provide the best solution to keep your water quality high. Our treatments are efficient and accurate, avoiding the wrong chemicals that could make things worse. Our expert support team is happy to discuss with you and find the optimal answer to your problem.
